| Range | Bore Dia | Rod Dia | Stroke | Pressure | Sensor |
|---|---|---|---|---|---|
| Minimum | 32 | 18 | 0.5 | 20 | LVDT Reed Switch Proximity Draw Wire |
| Maximum | 450 | 280 | 6500 | 375 | |
| Scalable to | 880 | 630 | 450 |
| Mounting | Function | Construction |
|---|---|---|
| Trunnion | Single Acting | Mill Duty |
| Clevis | Double Acting | Welded |
| Foot Lug | Tandem | Tie Rod |
| Flange | ||
| Swivel Foot |
